设备Equipment | |
输送带边走边裁 Belt cutting while running | 标准 standard |
裁刀偏移自动纠正系统 (压力传感器)Automatic correction system for cutter offset(Pressure sensor) | 标准 standard |
横向移动(二工位)Horizontal movement (two work stations) | 标准 standard |
门幅加宽(2米) Cutting width widening (2 m) | 标准 standard |
冷却装置 Cooling device | 选配 optional |
定位针装置 Positioning needle device | 选配 optional |
钻孔装置 Drilling device | 选配 optional |
性能performance | |
压缩面料高度 Compress fabric height | 8.5 CM |
最大裁剪速度 Max cutting speed | 50 m/min |
最大加速度 Max acceleration | 5 m/s2 |
裁刀尺寸Cutter size | 2.4 mm × 8.5 mm |
振动频率Vibration frequency | 3600 rpm |
有效裁剪窗口长度 Effective cutting window length | 1.8 m |
有效裁剪窗口宽度 Effective cutting window width | 2 m |
平均功耗Average Power | < 10 KW |
